ZEISS O’Detect with ZEISS INSPECT

ZEISS O’Detect with ZEISS INSPECT VMM | On top of things

The combination of optical and tactile measurement makes ZEISS O-DETECT with ZEISS INSPECT a real multitasker for a wide range of measurement tasks in various industries. ​The visual measuring machine (VMM) is designed for optimum quality assurance through high-quality images. Optical inspection can be easily expanded to include tactile measuring with the stylus systems available for ZEISS O-DETECT.

Highlights

Two cameras
that see it all

This solution is equipped with two cameras to keep an overview at all times. An integrated overview color camera locates the part more quickly to start measuring. The excellent ZEISS optics of the measurement camera combined with the ZEISS Digital Zoom provide a large field of view with high resolution – for greater efficiency and the capture of more details. Together with ZEISS image processing technology, it transforms images into precise measurement results.

No extensive preparation needed

With ZEISS O-DETECT and ZEISS INSPECT, your parts can be inspected from the beginning with minimal preparation required beforehand. The user just needs to secure the object into a fixture, place it onto the glass then commence inspection. Despite the quick start of the evaluation, there is no compromise on accuracy.

Powered by ZEISS INSPECT for intuitive use

ZEISS O-DETECT seamlessly operates with ZEISS INSPECT. The all-in-one, user-centered software solution is the established standard in 3D metrology. Benefit from intuitive functions, such as collision free path planning, automatic selection of measuring strategies and a Virtual Measuring Room (VMR) as your central control and measurement planning element.

Features

Lights that make a difference

With its different illumination options, this solution adapts seamlessly to your inspection tasks. Lights adapt to your individual part surface; by varying lights illuminating your part from the top. The diffuse light source enables measurement of shiny or reflective parts. The back light from the bottom enhances the edge quality for even more precise optical inspection if the contours of an object need to be checked.

Styli for measuring on the spot

Sometimes optical measurement isn’t enough. For hard-to-reach areas of interest, ZEISS O-DETECT with ZEISS INSPECT offers an easy extension to tactile measurement. The passive stylus system ZEISS XDT is made for precise tactile measurements due to the stable probing behavior during part inspection.

Guided part programming

Part programming is essential for ensuring accurate measuring results and ZEISS INSPECT can easily guide you through this process, achieving fast and repeatable measuring plans for series inspection with the highest data quality.

High-precision measurement results

ZEISS O-DETECT with ZEISS INSPECT produces outstanding results. Calibrated to MPE EU(3D) in accordance with ISO 10360, it delivers reliable and comparable 2D and 3D data every time.

Technical Data



Measuring volume

Field of view

Length measurement error MPE (EU)



Camera

Software

O’Detect 3/2/2

300 x 200 x 200 mm3

8.4 x 7.0 mm2

in 2D: 1.9 μm + L /150 μm
in 3D: 2.4 μm + L /150 μm

ZEISS INVENTA D1

ZEISS INSPECT

O’Detect 5/4/3

500 x 400 x 300 mm3

8.4 x 7.0 mm2

in 2D: 1.9 μm + L /150 μm
in 3D: 2.4 μm + L /150 μm

ZEISS INVENTA D1

ZEISS INSPECT
